SC Connector Passive Fiber Optics
Description
The SC is a snap-in connector that is widely used in single mode systems for its performance. The SC connector is also available in a Duplex configuration. They offer low cost, simplicity, and durability. SC connectors provide for accurate alignment via their ceramic ferrules. They feature a 2.5 mm Ferrule and molded housing for protection. Typical matched SC connectors are rated for 1000 mating cycles . View all Fiber Optic Connectors.
₺0,00
0 People watching this product now!
Bugün teslimat
Ücret, rotaya bağlıdır
Kuryemiz belirtilen adrese teslim edecektir
2-3 Gün
Ücret, rotaya bağlıdır
DHL kurye belirtilen adrese teslimat yapacaktır.
4-5 Gün
Ücret, rotaya bağlıdır
1 yıl
5 Günlük
Description
Applications
- Telecommunication
- LAN & WAN
- Broadband
- CATV
- Network
- FTTX
Features
- PC, UPC, APC polishing
- Various type such as FC , SC, ST, LC, MU, DIN, E 2000 , MTRJ,…
- Single mode and multi mode
- Low insertion loss
Specification
| item | single mode | multi mode |
| Insertion loss (DB) | ≤0.16 | ≤0.16 |
| Return loss (DB) | PC≥45 , UPC ≥50 ,APC ≥65 | N/A |
| Repeatability (DB) | 1000 times variable ≤0.2 | 1000 times variable ≤0.2 |
| Interchangeability (DB) | ≤0.2 | ≤0.2 |
| Temperature (C) | _40 ~ +80 | _40 ~+80 |
| Cable diameter | 0.9 mm, 2.0 mm ,2.8 mm available | |
