khorshid LED Recessed Ceiling Light Indoor Lighting
Khorshid LED panel light is high-grade indoor lighting Designed to fit in a wide range of ceiling types. this family of highly versatile panel lights can fulfill the majority of project requirements in most applications. Thanks to the high transmittance light guide plate, khorshid creates well-distributed which looks soft, bright, and comfortable, and is also favorable for the user’s eyesight. This LED panel light with high brightness SMD LED as light source, is ideal for the solution in offices, hotel, hospitals, office buildings or the other collective spaces where a high-level visual comfort is needed.
₺0,00
Bugün teslimat
Ücret, rotaya bağlıdır
Kuryemiz belirtilen adrese teslim edecektir
2-3 Gün
Ücret, rotaya bağlıdır
DHL kurye belirtilen adrese teslimat yapacaktır.
4-5 Gün
Ücret, rotaya bağlıdır
1 yıl
5 Günlük
Description
Features
– Accurate thermal design to achieve maximum luminous efficiency and lifetime and minimum luminous flux depreciation
– Higher than 80% color rendering index
– Designed to fit in a wide range of ceiling types in recessed, surface mounted and suspended applications
– provide a quite uniform light distribution and high light transmittance without any glare thanks to the high-quality light guide
– applicable to various public places such as office buildings, airports, factories and anywhere you need glare-free, soft and eye-friendly light
LED panel lights are products with unique characteristics and are perfect options for internal lighting (Home, office, commercial buildings). The thickness of this delicate light (11mm) is incomparable with other lighting products. Khorshid LED panel is made with SMD LED technology, based on LED plates; and has a uniform, soft and smooth light without any dazing. Khorshid is producible in the diversity of forms and shapes and installable easily as to surface and recess. High lumen efficiency and very high lifetime are other advantages of Khorshid panel light.
| parameter | 36W | 54W |
| nominal input voltage and frequency (V-AC/Hz) | 230/50 | 230/50 |
| input voltage and frequency range (V-AC/Hz) | 180~265/50~60 | 180~265/50~60 |
| nominal input power w | 36 | 54 |
| nominal input current a@v | 230@0.165 | 230@0.25 |
| power factor | 0.95 | 0.95 |
| led module operating voltage v dc | 33 | 33 |
| nominal power of single led w | 0.2 | 0.2 |
| total harmonic distortion thd | 15%> | 15%> |
| led module type | Integrated | Integrated |
| class of protection against electric shock 230v | I | I |
| parameter | 36W | 54W |
| light source led | SMD LED | SMD LED |
| number of leds in the module pcs | 192 | 288 |
| luminous flux lm | 4500 | 6480 |
| luminous efficiency lmw | 125 | 120 |
| color temperature k | 6500 | 6500 |
| color rendering index | 85 | 85 |
| sdcm initial and value | 5SDCM | 5SDCM |
| photometric code | 865/559 | 865/559 |
| lumen maintenance code | 9 | 9 |
| parameter | 36W | 54W |
| body material | Aluminum | Aluminum |
| Diffuser Material | PS | PS |
| body coating | Electrostatic powder painting | Electrostatic powder painting |
| weight kg | 2.1 | 2.6 |
| dimension (mm) | L595×W595×H11 | L595×W595×H11 |
| rated ambient temperature tq related to performance for the luminaire | 25 |
| working temperature range °c | 45+ ~ 20- |
| maximum allowed humiding % | 95 |
| rated median useful life l 70 b 50 hrs | 50000 |
| rated abrupt failure value % | 15 |
| power | 36W | 54W |
| code | 320036 | 320054 |
| IES LM – 80 | Measuring Luminous Flux and Color Maintenance of LED Packages, Arrays and Modules |
