Azarakhsh 3 Led Linear Flood Lights Outdoor Lighting
– High efficiency which makes low energy cost in decorative lighting projects
– Excellent light distribution curve can be applied corresponding to the lighting project
– Simple electrical installation thanks to through wiring ability
– Precise stainless steel fixing bracket due to setting the best beam pattern to lighting target
– Good ingress and impact protection in outdoor applications
₺0,00
0 People watching this product now!
Bugün teslimat
Ücret, rotaya bağlıdır
Kuryemiz belirtilen adrese teslim edecektir
2-3 Gün
Ücret, rotaya bağlıdır
DHL kurye belirtilen adrese teslimat yapacaktır.
4-5 Gün
Ücret, rotaya bağlıdır
1 yıl
5 Günlük
Description
Technical Data
electrical characteristics
| parameter | 36W |
| nominal input voltage and frequency (V-AC/Hz) | 230/50 |
| input voltage and frequency range (V-AC/Hz) | 220~240/50~60 |
| nominal input power w | 36 |
| nominal input current a v | 0.175@230 |
| power factor | 0.9 |
| led module operating voltage v dc | 216 |
| total harmonic distortion thd | 45%> |
| led module type | Integrated |
| class of protection against electric shock 230v | I |
Optical Characteristics
| parameter | 36W |
| light source led | High Power LED |
| number of leds in the module pcs | 36 |
| nominal power of led w | 1.5 |
| luminous flux lm | 3600 |
| luminous efficiency lmw | 100 |
| color temperature k | 3000, 4000, 5000, 6500 |
| color rendering index | 75 |
| sdcm initial and value | 5SDCM |
| photometric code | 730/559, 745/559, 750/559, 765/559 |
| lumen maintenance code | 9 |
| Light distribution angle (degrees) | 10,25,45,60 |
Mechanical characteristics
| ingress protection ip | IP65 |
| body material | Aluminum extrude |
| Diffuser Material | Flat Tempered glass |
| body coating | Anodized Plating |
| weight kg | 1.8 |
| dimension (mm) | L1000xW58xH69 |
General Characteristics
| rated ambient temperature tq related to performance for the luminaire | 25 |
| working temperature range °c | -20 ~ +45 |
| maximum allowed humiding % | 95 |
| rated median useful life l 70 b 50 hrs | 40000 |
| rated abrupt failure value % | 15 |
product code
| power | 36W |
| code | 391036 |
global standards
| IEC 62384 | DC or AC supplied electronic control gear for LED modules – Performance requirements |
| IES LM – 80 | Measuring Luminous Flux and Color Maintenance of LED Packages, Arrays and Modules |
| IEC 62722-2-1 | Luminaire performance – Part 2-1: Particular requirements for LED luminaires |
